RS100 High Torque/Speed Micro Servo Winch


5 in stock

Categories: ,


RS100 High Torque/Speed Micro Servo Winch

Comes with our custom Cnc aluminum micro spool

Winch controller built in, no controller needed!

Splashproof/ Resistant, NOT Submersible

Full Cnc Aluminum Case

Hardened Steel Gears

Quality Coreless Motor

Spline: 25T 4.9mm Micro

Voltage: 5v-8.4v

Bearing: 2BB

Wire Length: 185mm

Weight: .70 oz / 20 Grams Without Spool

Dimensions: 23 x 12 x 26mm

Torque: 90oz/ 6.5kg @ 5v

100oz/ 7.2kg @ 6v

120oz/ 8.6kg @ 7.4v

130oz/ 9.4 @ 8.4v

Speed: .10 @ 5v

.08 @ 6v

.07 @ 7.4v

.06 @ 8.4v

*Adapter Plate available separately

Warranty: 6 Month Warranty from all mechanical and electrical defects. We assume no liability of damage caused by mistreatment, abuse, water damage, or any use other than recommended. 8.4v Max. Nothing is unbreakable! For all warranty issues, you will need to send the servo to us to be inspected.
